150kg/h New Single Screw Pasta Macaroni Extruding Machine Line
Introduction of Single Screw Pasta Macaroni Extruding Machine Line
1. Description: This industrial pasta making machine/line/plant/industry pasta
making machine/macaroni pasta making machine/pasta production line
is produced by single-screw extruder through extruding cooking; the
macaroni pasta can be different shapes like shell, spiral, square
tube, circle tube, and so on. After drying, the maxaroni pasta
needs frying to get expanded.
2. Technical Advantages : Compact structure novel design and stable performance,developed
on the base of like produces and requirements in the world
market.It realizes high automation,convenient operation,low energy
and small floor space,that assures all working procedures from
feeding flour to finished once.The investment for this line is only
one tenth of that larger size equipment ,especially suitable to
small-size or self-owned enterprise.
3. Raw materials: adopts potato starch, corn starch, cassava starch, wheat flour,
corn flour etc as raw materials
4. Products: This industrial pasta making machine/line/plant/industry pasta
making machine/macaroni pasta making machine/pasta production line
can be used to produce Shell, spiral, square tube, circle tube
shapes
5. Capacity: 100-120kg/h,280-300kg/h
6. Flow chart:Mixing system---Extrusion system----Cutting system---Drying
system---Frying system---Flavoring System --Packing system
Product samples:
Function and parameter of main parts of Single Screw Pasta Extruder
1. Feeding System
Installed in the main machine, which feeds materials spirally, and
the quantity can be adjusted. This system includes engine, screw,
blender and machine shelf. The blending wing is used to prevent
roller empty although the materials are inside. The speed should be
better if the materials are neither accumulated nor stop.
2. Extruding System
Adopts the crafts what can make the materials ripe in the low
temperature by blending, cutting and extruding. Temperature control
is set strictly on the roller and screw to reach criteria the
materials require, thus the stable production can be adjusted
according to the food shapes, and enable the materials come out
easily and not adhere to the cutter.
3. Cutting System
Includes engine, shelf, cutter and transmitting system. The shelf
is fixed on the head of the moulds; and turns and cuts the
materials motivated by the belt wheel, the speed of which should be
subject to the type of products.
4. Heating System
Divides five areas, and the heating temperature of which can be
adjusted separately.
5. Transmitting System
The motive power from the main engine is transmitted to the screw
through the triangle belt and decelerator. This system adopts the
frequency & speed technology with reliable adjustment.
6. Controlling System
Can control all the components of the main machine centrally. The
operation is easy and auto protecting instruments and dashboard.
7.Besides above system,we also have new design with this
machine--Vacuum Pump.For the pasta and macaroni,the big problem is
with bubbles and air inside.With the vacuum pump,which can extract
air from feeding part,so there will be no any air and bubbles
inside the pasta and macaroni,and with the vacuum pump,the finished
product will not easy broken and taste also very srong and good.
Machine packing and delivery:
Test video:
Any interest, please be free to contact us for best price.
