2019 New Fabrication Pet food Extruding Line
Pet food process line endues pet food with the amount of nutrition,
digestible structure, novel shape, and unique taste to meet with
the needs of modern market. This kind of food not only can provide
nutrition to dogs, like protein, fat, vitamin, etc, but also
satisfy the dog nature hobby, benefit to its strong teeth,
cleanness of mouth and teeth, and prevents disease.
Pet food machine line we use extruder as main machine to make the
raw material puffed and easy for pet to eat .then use some specaial
flavorying make the test to be better for different pet .
☆ The screw is made of alloy (38CrMoAL) by nitriding process, high
strength and wear-resting. And it has good self-cleaning ability
and does not need to discharge or clean the barrel and screw, when
roasting or replacing of materials.
☆It adopts speed-adjusted converter on feeding system, extrusion
system and cutting system. Food grade stainless steel twin screw
feeding machine guarantees stable materials feeding in the whole
food process.
☆ The gearbox has automatic lubrication function, with extends gear
life.
☆ Radiator is increased on driving part for forced cooling effect,
and it ensures extruder operate safely.
☆ Barrel with water-cooled circulation, raw materials not only for
corn/rice, also for wheat flour/starch with high viscosity.
Different moisture-extrusion temperature ratio, whole-expanded and
half expanded as different type of products.
☆ Cutting knife fixed in the die head seat, rotary cutting by
V-belt drive.
Parameter
| Type | SRT-65 | SRT-70 | SRT-85 | SRT-90 | SRT-95 |
| Capacity | 120-150kg/hr | 200-300kg/hr | 500-600kg/hr | 800-1000kg/hr | 2000kg/hr |
| Power | 80kw | 90kw | 150kw | 200kw | 250kw |
| Dimension | 18 x 5x 3m | 20 x 5x 3m | 30 x 5x 4m | 35 x 5x 5m | 40 x 10x 16m |
