Complete Cracker Biscuit Production Line Oat Cookies Making Machine
Introduction of 100kg/h Full Automatic Dog Cookies Production Line:
The biscuit production line can be combined and displayed according to customer's local space
or biscuit making technical requirement. By changing the moulds and
recipes, this plant is able to produce various types of high
quality biscuit. Such as cream biscuit, sandwiching biscuit,soda
cracker biscuit,vegetable biscuit etc., There are diversify heating
source for your operation (electric, gas, fuel oil) .
Production process
Dough making → Biscuit forming → Baking → Oil sprayer → Cooling →
Stacking→ Packing
To get a hard biscuit the dough ribbon is formed by using a roller
extruder. The formed ribbon pass through a laminator with multiple
rolling and resting. To give the dough a layered structure the
continuous dough is being laid as an “envelope” at the exit of the
laminator. Getting a ribbon of a given thickness with preserving
the structure of dough is carried out on a three-modular rolling
machine.
Remains of dough ribbon after the forming of dough pieces can be
returned for usage and, as a rule, the dough ribbon formed out of
them is fed together with the ribbon from the laminator to the
rolling machine.
The device may contain :100kg/h per hour full automatic biscuit making machine
1>Dough Mixer /Dough biscuit machine/ Dough mixer for biscuit
2>Integrated forming machine for soft biscuit and hard biscuit
3>Salt/sugar spreading machine
4>Biscuit tunnel oven
5>Biscuit oil sprayer
6>Cooling conveyor for biscuit
7>Biscuit packaging machine
8>Biscuit filling machine (Optional for sandwich crackers)
How to get a quotation : full automatic biscuit making machine
Different dough roll width meets different productivity capacity.
Please provide the following details, so that we can provide
professional solutions and quotations.
1.The kinds of biscuit you will produce. Sample picture is welcome.
2.The production capacity you need. Different model meets different
productivity capacity.
Technical parameter:
| Production line name | Biscuit production line |
| Automatic biscuit production line, high degree of automation, from
the feeding calendering, molding, waste recycling, drying, fuel
injection, cooling fully automatic one-time completion, providing
hundreds of molds and dozens of process recipes, by changing the
mold and process recipes Produce a variety of biscuits on the
market, such as butter biscuits, sandwich biscuits, ultra-thin
biscuits, soda crackers, animal biscuits, multi-dimensional
biscuits, vegetable biscuits, etc. |
| Voltage | 380V/50HZ(can customize) |
| Power | 28.5kw |
| Impression roll | 205*205mm |
| Baking temperature | 200~300℃ |
| Working width | 200mm |
| Capacity | 50kg/h |
Machine details and samples:
Video:
Any interest about the machine, please be free to contact us!
